6104: ROOF PANEL & BACK WINDOW GLASS
| Number | Part Name | Code | Note | Qty Req'd | Prod. Date |
|---|---|---|---|---|---|
| 320117200 | GLASS SUB-ASSY, REMOVABLE ROOF | 63201L | SW2#..CP | 1 | 01.1990 - 06.1995 |
| 329512020 | PAD, ROOF WIND DEFLECTOR PANEL | 63295B | SW2#..CP | 2 | 01.1990 - 06.1995 |
| 352054010 | SCREW | 9352054010 | N/A | 2 | N/A |
| 320917020 | PANEL SUB-ASSY, ROOF WIND DEFLECTOR | 63209 | SW2#..CP | 1 | 01.1990 - 06.1995 |
| 363717010J0 | GARNISH, REMOVABLE ROOF | 63637 | SW2#..CP DARK BLUE, TRIM 8# | 1 | 01.1992 - 11.1993 |
| 363717010B0 | GARNISH, REMOVABLE ROOF | 63637 | SW2#..CP BLACK, TRIM 2# | 1 | 01.1992 - 06.1995 |
| 363717010A0 | GARNISH, REMOVABLE ROOF | 63637 | SW2#..CP IVORY, TRIM 0# | 1 | 01.1992 - 06.1995 |
| 327712010 | SPACER, REMOVABLE ROOF LOCK BASE | 63277B | SW2#..CP | 1 | 01.1990 - 06.1995 |
| 325017011 | BASE ASSY, REMOVABLE ROOF LOCK | 63250 | SW2#..CP | 1 | 01.1990 - 06.1995 |
| 322717010 | CLIP, ROOF WIND DEFLECTOR PANEL | 63227 | SW2#..CP | 1 | 01.1990 - 11.1993 |
| 017906070 | NUT | 9017906070 | N/A | 2 | N/A |
| 327112010J0 | GARNISH, REMOVABLE ROOF LOCK | 63271 | SW2#..CP DARK BLUE, TRIM 8# | 1 | 01.1992 - 11.1993 |
| 327112010A0 | GARNISH, REMOVABLE ROOF LOCK | 63271 | SW2#..CP IVORY, TRIM 0# | 1 | 01.1992 - 06.1995 |
| 327112010B0 | GARNISH, REMOVABLE ROOF LOCK | 63271 | SW2#..CP BLACK, TRIM 2# | 1 | 01.1992 - 06.1995 |
| 325217030 | WEATHERSTRIP, REMOVABLE ROOF, INNER | 63252F | SW2#..CP | 1 | 01.1990 - 06.1995 |
| 352024010 | SCREW, TAPPING | 9352024010 | N/A | 2 | N/A |
| 616000600 | RING, E | 9616000600 | N/A | 2 | N/A |
| 326017023A0 | HANDLE ASSY, REMOVABLE ROOF LOCK | 63260 | SW2#..CP IVORY, TRIM 0# | 1 | 02.1993 - 06.1995 |
| 326017023B1 | HANDLE ASSY, REMOVABLE ROOF LOCK | 63260 | SW2#..CP BLACK, TRIM 2# | 1 | 02.1993 - 06.1995 |
| 326017023J1 | HANDLE ASSY, REMOVABLE ROOF LOCK | 63260 | SW2#..CP DARK BLUE, TRIM 8# | 1 | 02.1993 - 11.1993 |
| 015950074 | SCREW, W/ WASHER | 9015950074 | N/A | 1 | N/A |
| 616000400 | RING, E | 9616000400 | N/A | 2 | N/A |
| 328017010 | CATCH ASSY, REMOVABLE ROOF AUXILIARY, LH | 63280 | SW2#..CP | 1 | 01.1990 - 06.1995 |
| 331925014 | SCREW, W/ WASHER | 9331925014 | N/A | 2 | N/A |
| 320317070 | HOUSING SUB-ASSY, REMOVABLE ROOF | 63203H | SW2#..CP | 1 | 01.1990 - 06.1995 |
| 329712010 | BOLT, REMOVABLE ROOF HINGE CASE | 6329712010 | N/A | 1 | N/A |
| 281787013 | PROTECTOR, WIRING HARNESS | 8281787013 | N/A | 1 | N/A |
| 046400161 | CLAMP | 9046400161 | N/A | 2 | N/A |
| 046714001 | CLIP | 9046714001 | N/A | 4 | N/A |
| 327517010 | HOLDER, REMOVABLE ROOF HINGE, RH | 63275 | SW2#..CP | 1 | 01.1990 - 06.1995 |
| 327617010 | HOLDER, REMOVABLE ROOF HINGE, LH | 63276 | SW2#..CP | 1 | 01.1990 - 06.1995 |
| 327812010 | SEAL, REMOVABLE ROOF HINGE CASE | 63278 | SW2#..CP | 2 | 01.1990 - 06.1995 |
| 327317040 | CASE, REMOVABLE ROOF HINGE, RH | 63273 | SW2#..CP | 1 | 09.1992 - 06.1995 |
| 324917040 | HOSE (FOR SLIDING ROOF OR REMOVABLE ROOF DRAIN) | 63218A | SW2#..CP RR | 2 | 01.1992 - 11.1993 |
| 324916070 | HOSE (FOR SLIDING ROOF OR REMOVABLE ROOF DRAIN) | 63218A | SW2#..CP L=1510,FR | 2 | 08.1992 - 11.1993 |
| 327417040 | CASE, REMOVABLE ROOF HINGE, LH | 63274 | SW2#..CP | 1 | 09.1992 - 06.1995 |
| 238117041 | WEATHERSTRIP, ROOF SIDE RAIL, RH | 62381A | SW2#..CP | 1 | 06.1991 - 09.1993 |
| 786920030 | CLIP (FOR REMOVABLE ROOF WEATHERSTRIP) | 67869A | SW2# | 8 | 01.1990 - 06.1995 |
| 238217041 | WEATHERSTRIP, ROOF SIDE RAIL, LH | 62382A | SW2#..CP | 1 | 06.1991 - 09.1993 |
